TRIPLE OFFSET VALVES

A newcomer in the Petrolvalves Product Line: the Triple Offset "AJ Series" Valve.

A valve characterized by a unique geometry featuring three offsets in a quarter turn design, to totally overcome friction during 90 degrees of rotation.
A torque-seated valve, with a metal-to-metal sealing and a conical design of seat and seal ring for bidirectional Zero Leakage tightness performance.
A highly technological valve, guaranteeing a superior degree of reliability over time.





AJ SERIES: CREATING VALUE.

High degree of Safety Performance and Reliability: Safety Integrity Level certified as SIL 3.
Recommended for valve protective function (i.e. ESD, EBO, trip turbine).
Fugitive Emissions containment optimized thanks to low-emission graphite packing, especially in presence of risk for exposure to VOC’s or other critical fluids. Certified ISO 15848-1.
Firesafe by design for its all-metal construction and firesafe-certified as per API 607.
Low and constant torque requirement for bidirectional tight shutoff performance.
Ease of operation.
Special antiblow out device to address any potential risk of shaft failure, in accordance with latest standard requirements.
All-metal construction for inherent anti-static feature, ensuring uninterrupted current flow.
Extremely compact design for weight and space control.
Maintenance reduced to minimum.






APPLICATIONS

A variety of industrial applications will benefit from the installation of TOV AJ Series - in isolation, on-off, control, high cycling, and quick acting services:

Oil & Gas onshore plants
Refineries and Storage Tanks
LNG - Liquefaction, Regasification, Terminals
Offshore platforms
FPSO, FLNG, FSRU
Petrochemical & Chemical
Process
Power
Desalination
Waterworks













PRODUCTION RANGE

Size Range: From 3" to 112"
Pressure Ratings: from ASME Class 150 to 900; EN 1092-1 from PN 10 to PN 160
Body styles: Double Flanged (short and long pattern), Lug, Wafer, Buttweld
Materials of construction: WCB, CF8M, CF3M, LCB/LCC, WC6, WC9, C5, C12, Duplex and SuperDuplex, Nickel and other Special Alloys
Valve configurations: Primary, Cryogenic ("no-access" standard cryo, and "top entry" cryo versions), High temperature.






AJ SERIES.
A NEW STANDARD OF RELIABILITY.

Today we are launching a new generation of valves providing premium performance & reliability:

A highly-technological process valve
Produced in an innovative Focus Factory
A new beacon for Italian manufacturing excellence




Contact us to receive TOV Brochure, thank you!
